5. Board Update Portal
The Stratix IV E FPGA Development Kit ships with the Board Update Portal design
example stored in the factory portion of the flash memory on the board. The design
consists of a Nios II embedded processor, an Ethernet MAC, and an HTML web
server.
When you power up the board with the PGM CONFIG SELECT rotary switch (SW5)
in the 0 position, the Stratix IV E FPGA configures with the Board Update Portal
design example. The design can obtain an IP address from any DHCP server and
serve a web page from the flash on your board to any host computer on the same
network. The web page allows you to upload new FPGA designs to the user hardware
portion of flash memory, and provides links to useful information on the Altera
website, including kit-specific links and design resources.
1
After successfully updating the user hardware flash memory, you can load the user
design from flash memory into the FPGA. To do so, set the PGM CONFIG SELECT
rotary switch (SW5) to the 1 position and power cycle the board.
The source code for the Board Update Portal design resides in the <install
dir> \kits\stratixIVE_4se530_fpga\examples directory. If the Board Update Portal is
contents.
Connecting to the Board Update Portal Web Page
This section provides instructions to connect to the Board Update Portal web page.
1
Before you proceed, ensure that you have the following:
■
■
■
A PC with a connection to a working Ethernet port on a DHCP enabled network.
A separate working Ethernet port connected to the same network for the board.
The Ethernet and power cables that are included in the kit.
To connect to the Board Update Portal web page, perform the following steps:
1. With the board powered down, set the PGM CONFIG SELECT rotary switch
(SW5) to the 0 position.
2. Attach the Ethernet cable from the board to your LAN.
3. Power up the board. The board connects to the LAN’s gateway router, and obtains
an IP address. The LCD on the board displays the IP address.
4. Launch a web browser on a PC that is connected to the same network, and enter
the IP address from the LCD into the browser address bar. The Board Update
Portal web page appears in the browser.
June 2011
Altera Corporation
Stratix IV E FPGA Development Kit User Guide
